Humminbird 1198c SI Fishfinder Combo

Great for your next fishing trip, the Humminbird 1198c SI Fishfinder Combo is made with a waterproof casing to help protect against the elements. This fishfinder is designed with a 10.4" 4:3 color TFT display with an LED backlight for clarity and Side Imaging® and DualBeam PLUS™ sonar with SwitchFire™ and Selective Fish ID+ to help locate your next big catch in changing fishing conditions. 3-D map viewing and a split-screen zoom help you find the perfect spot, while the SD card stores up to 2,750 waypoints, 45 routes and 50 tracks with 20,000 points each.

Features and Benefits

• 10.4" 4:3 color TFT display with an LED backlight and 600 x 800 resolution for a clear view
• 3-D map viewing and a split-screen zoom help you find the perfect spot
• Side Imaging® and DualBeam PLUS™ sonar with SwitchFire™ and Selective Fish ID+ help you locate your next catch in changing fishing conditions
• Freeze Frame technology allows you to mark structures and waypoints and magnify selected returns
• Transom transducer with a built-in temperature gauge
• GPS with preinstalled ContourXD cartography; compatible with optional LakeMaster® and Navionics® charts
• SD card stores up to 2,750 waypoints, 45 routes and 50 tracks with 20,000 points each
• Waterproof casing provides protection from the elements
• TrueArch technology
• Selectable display and background colors
• In-dash mounting system
• Network upgradeable
• iPilot® Link™

User Manual:

Click here for User Manual

Installation Guide:

Click here for Installation Guide

Manufacturer Warranty (general):

1 year

Portable:

No

Memory Card Slot:

SD card

Product Height (in.):

9.3

Color Display:

Yes

Product Width (in.):

13.1

Frequency (khz):

200/20° @ - 10 dB, 83/60° @ - 10 dB (DualBeam PLUS™); 455/86° @ - 10 dB, 800/55° @ - 10 dB (HD Side Imaging®/Down Imaging)

Display Pixel Resolution:

600 x 800

Number Of Routes:

45

Manufacturer Warranty - General:

1 year

Number Of Plot Trails:

50

Product Depth (in.):

2.9

Maximum Depth (ft.):

1,500

Antenna Type And Location:

GPS

3-d Map View:

Yes

Number Of Waypoints:

2,750

Display Size (in.):

10.4

Product Weight (oz.):

48

Preloaded Maps:

ContourXD

Rms Transmit Power (w):

1,000

• Humminbird 1198c SI Fishfinder Combo
• Owner's manual
